Insert Ball Bearing

UC 200 Series		d mm	D mm	B mm	≈ KGS
UC 201		12	47	31	0.200
UC 202		15	47	31	0.180
UC 203		17	47	31	0.170
UC 204		20	47	31	0.150
UC 205		25	52	34.1	0.200
UC 206		30	62	38.1	0.310
UC 207		35	72	42.9	0.470
UC 208		40	80	49.2	0.620
UC 209		45	85	49.2	0.690
UC 210		50	90	51.6	0.800
UC 211		55	100	55.6	1.070
UC 212		60	110	65.1	1.490
UC 213		65	120	65.1	1.720
UC 214		70	125	74.6	1.960
UC 215		75	130	77.8	2.140
UC 216		80	140	82.6	2.710
UC 217		85	150	85.7	3.410
UC 218		90	160	96	4.080
UC 219		100	180	108	4.500
UC 300 Series		d mm	D mm	B mm	≈ KGS
UC 305		25	62	38	0.330
UC 306		30	72	43	0.536
UC 307		35	80	48	0.694
UC 308		40	90	52	0.954
UC 309		45	100	57	1.285
UC 310		50	110	61	1.637
UC 311		55	120	66	2.070
UC 312		60	130	71	2.600
UC 313		65	140	75	3.174
UC 314		70	150	78	3.790
UC 315		75	160	82	4.520
UC 316		80	170	86	5.320
UC 317		85	180	96	6.480
UC 318		90	190	96	7.330
UC 319		95	200	103	8.810
UC 320		100	215	108	10.710
UC 322		110	240	117	14.550
UC 324		120	260	126	18.470
UC 326		130	280	135	22.980
UC 328		140	300	145	27.980

UK Series		d mm	D mm	B mm	≈ KGS
UK 205		20	52	23	0.250
UK 206		25	62	26	0.370
UK 207		30	72	29	0.540
UK 208		35	80	31	0.700
UK 209		40	85	32	0.830
UK 210		45	90	34	0.980
UK 211		50	100	36	1.240
UK 212		55	110	40	1.580
UK 213		60	120	41	1.880
UK 215		65	130	44.5	2.620
UK 216		70	140	46	3.230
UK 217		75	150	48	3.900
UK 218		80	160	51	4.620

SA Series		d mm	D mm	B mm	≈ KGS
SA201		12	40	28.6	0.130
SA202		15	40	28.6	0.130
SA203		17	40	28.6	0.130
SA204		20	47	31	0.150
SA205		25	52	31	0.220
SA206		30	62	35.7	0.300
SA207		35	72	38.9	0.500
SA208		40	80	43.7	0.670
SA209		45	85	43.7	0.730
SA210		50	90	43.7	0.830
SA211		55	100	48.4	0.870
SA212		60	110	53.1	1.300

SB Series		d mm	D mm	B mm	≈ KGS
SB201		12	40	22	0.100
SB202		15	40	22	0.100
SB203		17	40	22	0.100
SB204		20	47	25	0.150
SB205		25	52	27	0.180
SB206		30	62	30	0.270
SB207		35	72	32	0.420
SB208		40	80	34	0.600
SB209		45	85	41.2	0.800
SB210		50	90	41.6	0.830
SB211		55	100	45.3	1.100
SB212		60	110	53.7	1.300

UC 200 Series		d mm	D mm	B mm	≈ KGS
UC 201		12	47	31	0.200
UC 202		15	47	31	0.180
UC 203		17	47	31	0.170
UC 204		20	47	31	0.150
UC 205		25	52	34.1	0.200
UC 206		30	62	38.1	0.310
UC 207		35	72	42.9	0.470
UC 208		40	80	49.2	0.620
UC 209		45	85	49.2	0.690
UC 210		50	90	51.6	0.800
UC 211		55	100	55.6	1.070
UC 212		60	110	65.1	1.490
UC 213		65	120	65.1	1.720
UC 214		70	125	74.6	1.960
UC 215		75	130	77.8	2.140
UC 216		80	140	82.6	2.710
UC 217		85	150	85.7	3.410
UC 218		90	160	96	4.080
UC 219		100	180	108	4.500
UC 300 Series		d mm	D mm	B mm	≈ KGS
UC 305		25	62	38	0.330
UC 306		30	72	43	0.536
UC 307		35	80	48	0.694
UC 308		40	90	52	0.954
UC 309		45	100	57	1.285
UC 310		50	110	61	1.637
UC 311		55	120	66	2.070
UC 312		60	130	71	2.600
UC 313		65	140	75	3.174
UC 314		70	150	78	3.790
UC 315		75	160	82	4.520
UC 316		80	170	86	5.320
UC 317		85	180	96	6.480
UC 318		90	190	96	7.330
UC 319		95	200	103	8.810
UC 320		100	215	108	10.710
UC 322		110	240	117	14.550
UC 324		120	260	126	18.470
UC 326		130	280	135	22.980
UC 328		140	300	145	27.980
